300 Gallon Ketchup Sour Cream Production Stainless Steel Homogenizer Emulsifier
Quick Detail:
- Tank type: Homogenizer Emulsifier
- Material : Stainless steel SS304 SS316L
- Agitator : Top/Bottom Homogenizer, Emulsifing,High shear,scraper, propeller etc
- Equipment function: Homogenizer/Mixing/heating/cooling/vacuum/weighing/homogenizer/scraper/cleaning
- Controller box: Automatic PLC, Buttons type
- Safety Features: E-Stop
- Voltage: 220V/380V/415V/480V
- Warranty: 1 Year
- Application: Chemical, detergents,cosmetic,food,pharmaceutical
- Capacity: 100 gallon-1000 gallon, customize available
Description:
The Vacuum Emulsifier Homogenizer is a complete system for manufacturing viscous emulsion,dispersion and suspension in either small-scale or large-scale, Emulsions are prepared by adding one phase to the other over time, with one or both phases containing emulsifier, and applying shear. In some cases, one or both phases are heated prior to mixing to aid emulsification. The phases are mixed until the mean droplet size is within specification, Which can be used for a wide variety of material including, but not limited to: foods, herbs, papers, liquids, jells, powders, plastics resins, epoxies and many other parts and materials. The in-vacuum capability allows a large quantity of material to be mixed and degassed for enhanced performance.
Specifications:
| Material | Stainless steel SS304 SS316L |
| Dimension | As per Design |
| Capacity | 100 gallon-1000 gallon, customize available |
| Mixing speed | 1-3000RPM |
| Tank struction | Double jacketed tank |
| Outlet | Bottom outlet |
| Agitator | Homogenizer & scraper blade |
| Agitator type | Top mixer bottom homogenizer |
| Motor Brand | Siemens |
| Tank Cover Type | Hingle/Sealed/Removable |
The high-shear emulsifier is a machine that can fully refine and uniformly refine materials. Its name should come from the machine that can promote the mixing of oily substances (oil phase) and water-based substances (water phase) to form a uniform emulsion. The high shear emulsifier has the functions of refining, dispersing and homogenizing. It is mainly used for liquid-liquid emulsification and homogenization, and liquid-solid (powder, small particles) fine dispersion. Mechanical and hydraulic high-speed shearing force is the key to the operation of the high-shear dispersing emulsifier. The high-speed rotating rotor and stator are precisely matched, resulting in high shear linear speed and high-frequency mechanical effects that bring about mechanical shearing and hydraulic shearing. force to ensure that the material can withstand hundreds of thousands of shears per minute. The material is subjected to strong centrifugal extrusion, shearing, spraying, liquid layer friction, collision, and tearing in the precise gap between the stator and rotor of the high-shear dispersing emulsifier. Under the combined action of complex liquid flows such as cracking and turbulence, turbulence, and vortex, the immiscible liquid phase, liquid gas phase, and liquid solid phase can be mixed and dispersed uniformly and finely in an instant under the combined action of corresponding mature process conditions. , homogenization, emulsification, and so on, and finally obtain high-quality products.
Application:
The Vacuum Emulsifier Homogenizer is a complete system for manufacturing viscous emulsion,dispersion and suspension in either small-scale or large-scale cosmetic,pharmaceutical,food and chemical industries.
Tags: #vacuumemulsifier #homogenizeremulsifier #emulsifier #vinegermixer #ointmentmixer #skincareproducts #homogenizer
